Products

BWP PLYWOOD - IS 710


BWP grade plywood is the bestseller product among the other products offered by KHAJA PLY owing to its unique bonding strength and durability.

Manufacturing

• Made from uniform quality veneer, selected from hard wood species such as gurjan , teak ,redgum…
• Veneers are bonded with phenol formaldehyde BWP grade resin under high temperature using pre pressed technology.
• Treated with preservatives under vacuum pressure technology to ensure protection from attack by micro organisms.
• Specific stress receiving treatment given to check anti-warp properties which keeps it dimensionally stables in both excessive wet & dry condition through out its life.

Advantage

• 110% Borer proof & termite proof
• 100%guaranteed product

Application

• Cabinets in Kitchen and Bathroom.
• Ship/Bus Body Building.
• Panelling / Partitions / Ceiling / Wardrodes / Counters.

Available In

• 6 mm / 9 mm / 12 mm / 16 mm / 19 mm

Technical details
Test Results
Moisture Content 5% To 10%
Glue Sheer Strength (Dry State) More than 1350N
Adhesion of plies Excellent
Water Resistant test Water for 3 hours a) Indv. Min-784.5 (confirms to specified requirements).
b) Average - 980.7 (confirms to specified rqmnts.)
Glue Shear Strength Excellent
Adhesion of plies Excellent
Tensile Strength a) Parolee to grain more then 450 kn. / m2.
b) Right angle to grain more then 250 kn. / m2.
Mycological Test a) No Separation at edges after 21 days of exposure to micro organism.
b) Shear strength more than 1000 N
Specific Gravity 0.70 to 0.75
Water Absorption screw holding strength More than 250 kgs.
Nail Holding strength More than 250 kgs.

BWR PLYWOOD - IS 303


KHAJAPLY , every effort is made to keep the products the best in class.

Manuacturing Details

• Made from quality wood using selected hardwood veneers of uniform thickness and liquid PF Resin.
• Quality combination of imported and Indian Veneers-bonded together to create a sturdy ply.
• Chemically treating the ply against termites and borers.
• Stress-relieving processes by use of superior grade hardwood & other production processes augment the antiwarp properties - keeping the product stable throughout its life.

Advantages

• Withstand severe climatic and weather conditions. • Chemical additives prevent de-lamination and protect the plywood from micro-organisms.

Applications

• Kitchen Cabinets
• Elegant Interiors
• Attractive Furniture

Available in

• 6 mm / 9 mm / 12 mm / 16 mm / 19 mm

Technical details
Test Results
Moisture Content 5% To 10%
Glue Sheer Strength (Dry State) More than 1350N
Water Resistance Test More than 1000 N
Mycological Test Water Resistance Test
Boiling water Test No Delamination after boiling for 72 hrs.
Glue Adhesion Excellent
Specific Gravity 0.70 to 0.75
Screw Holding Strength More than 200 kgs
Nail Holding Strength Water Absorption More than 50 kgs. Less than 3 %

MR PLYWOOD - IS 303


Manuacturing Details

• Durable and Economical
• Suitable for warm & humid climatic conditions.
• Powder proof, termite resistant and reusable.

Advantages

• Withstand severe climatic and weather conditions. • Chemical additives prevent de-lamination and protect the plywood from micro-organisms.

Applications

• High quality furnitures, interior decoration

Available in

• 6 mm / 9 mm / 12 mm / 16 mm / 19 mm

Technical details
Test Results
Moisture Content 5% To 10%
Glue Sheer Strength (Dry State) More than 1000N
Water Resistance Test Water for 3 hours • a) No Delamination after submergine in 70C
b) Glue shear Strength more then 800n
Adhesion of Piles Excellent
Specific Gravity 0.60 to 0.65
Water Absorption Less then 3%
Screw Holding Strength More than 150 kgs
Nail Holding Strength Water Absorption More than 50 kgs.

SHUTTERING PLYWOOD - 4990


Manuacturing Details

• Made of the selected and naturally durable veneers impregnated with specially formulated phenolic resin and dried.
• Packed in encase in caul plates and laminated under very high pressure and heat.
• The sides are resealed by acrylic paint to preserve moisture absorption and swelling.

Advantages

• More retention of resin than any ISI grade shuttering Plywood results in substantial cost saving
• Improves construction speed and reduces manpower requirements.
• Ideal framework material for precast, concrete molds since it is free from dents, non-corrosive and imparts an evenly fine finish on the concrete surface, resulting in additional cost saving no re-plastering or finishing is required.

Applications

• Construction of all size bridges, water tanks, cooling towers, buildings.
• In chemical factories - for packing.
• Truck Body Manufacturing.

Available in

• Thickness (in mm) - 12 mm /Size - 8 feet X 4 feet./Weight – 30,34, kgs.

Technical details
Test Results
Moisture Content 5% To 15%
Glue Sheer Strength in dry condition -Individual Min. 1100 Newton
-Average Min. 1350 Newton
Tensile Strength
a . Parallel to grain condition.
b . Right angles to grain direction.
c . Sum of both direction
Min. 325 Kgf./ cm²
Min. 225 Kgf./cm²
Min. 225 Kgf./cm²
Modules of Elasticity
a . Modules of Elasticity
b . Perpendicular to grain direction
Min. 8000 Newton/mm²
Min. 4000 Newton/mm²
